What benefits can we bring to you
(1) For consumers: Our tracked transport vehicles are cost-effective and built for long service life—with wear-resistant tracks, a rugged chassis, and a reinforced cargo bed, they excel in harsh working conditions (such as construction sites, farmlands, and mining areas) without frequent maintenance. We offer models with load capacities ranging from 1.2 ton to 8 tons, perfectly meeting your diverse transportation needs (e.g., hauling sand, gravel, agricultural supplies, or mining materials). We also support full customization: Whether you need a specialized cargo bed (waterproof/anti-slip), additional safety guards, or modified track width for narrow terrain, we can tailor the vehicle to your exact requirements.
(2)For suppliers: We guarantee a sufficient profit margin to help you expand your market competitiveness. Meanwhile, we provide 1 years of after-sales service for all tracked transport vehicles—covering parts replacement, technical troubleshooting, and on-site maintenance guidance (if needed). Before delivery, every vehicle undergoes strict factory testing (including load-bearing tests, track performance checks, and engine operation verification) to ensure 100% quality compliance. Additionally, we offer free publicity support in your local market (e.g., localized product brochures, online platform promotions) and customize vehicle colors or print your brand trademarks on the body to strengthen your brand recognition.
Special reminder
Different customers have unique demands for tracked transport vehicles—such as custom colors, specialized configurations (e.g., hydraulic lifting cargo beds, led work lights), load capacity adjustments, or appearance modifications (e.g., extended cargo beds, protective bumpers). We will provide a detailed quotation based on your specific requirements, so the final price may vary. Thank you for your understanding.
The latest configuration notice
Our tracked transport vehicles now support two key upgrades to enhance work efficiency and comfort:
Optional enclosed cab with air conditioning—effectively shielding drivers from dust, rain, high temperatures, or cold weather, ensuring a comfortable operating environment even during long-hour shifts.
Equipped with high-power branded engines (e.g., renowned diesel/petrol engine brands with reliable performance)—delivering strong torque and stable power output, which guarantees smooth transportation even when hauling full loads on slopes or uneven terrain.
These upgrades ensure an optimal work experience for both drivers and operators, while maintaining the vehicle’s durability and load-bearing capacity.
- Equipped with an efficient and low consumption engine that meets the European Stage V emission standards
- Authoritative certification: Our products have passed international authoritative certifications such as CE and ISO9001. All designs and production comply with international safety and quality standards, and are globally recognized
- Key structural components are made of high-strength steel and wear-resistant materials, which undergo precise mechanical calculations and testing to ensure that the equipment remains sturdy and stable under heavy load conditions, resistant to deformation and wear, with excellent materials and durability
- Exquisite craftsmanship, multiple quality inspections, from flaw detection, cutting, welding, machining, assembly, and testing, each process passes through refined quality inspection procedures
- Comprehensive after-sales support provides a 1-year warranty for core components
- The machine has high-quality load-bearing performance and is not easily deformed during use
| Product Model | 2-ton Hand-held | Chassis Width | 1000MM |
| Overall Dimensions | 2500*1300*1350MM | Ground Contact Length | 1330 |
| Carriage Dimensions | 1600*1200*500MM | Coating Process | Full-system Integral Spray Molding |
| Engine Brand | Youpu / Changchai Group | Gearbox Model | Guli Type 18 |
| Engine Model | 195FA Air-cooled Diesel Engine | Crawler Specification Model | 230*72*56 |
| Battery Specification | 60A (Nationwide Warranty) | Self-weight | 682KG |
| Power | 12.5Ps | Load-bearing Configuration (Cast Iron) | 6 pieces of 150 Load-bearing Wheels |
| Product Model | 1.2-ton Hand-held | Chassis Width | 850MM |
| Overall Dimensions | 2200*1000*1330MM | Ground Contact Length | 1200 |
| Carriage Dimensions | 1400*1000*500MM | Coating Process | Full-system Integral Spray Molding |
| Engine Brand | Youpu / Changchai Group | Gearbox Model | Guli Type 15 |
| Engine Model | 188FA Air-cooled Diesel Engine | Crawler Specification Model | 230*72*46 |
| Battery Specification | 60A (Nationwide Warranty) | Self-weight | 549KG |
| Power | 9.4Ps | Load-bearing Configuration (Cast Iron) | 5 pieces of 150 Load-bearing Wheels |
| Product Model | 3-ton car type | Power | 25Ps |
| Overall Dimensions | 3460*1600*1550MM | Chassis Width | 1550MM |
| Cargo Box Dimensions | 2200*1600*560MM | Ground Contact Length | 1730 |
| Battery Specification | Single 120A (Nationwide Warranty) | Gearbox Model | Guli Type 21 |
| Engine | Quanchai 25HP, Single-cylinder Water-cooled | Crawler Specification Model | 350*90*56 |
| Self-weight | 1300kg | Load-bearing Configuration (Cast Iron) | 7 load-bearing wheels (180 each) per side |
| Product Model | 2-ton car type | Power | 18Ps |
| Overall Dimensions | 2700*1300*1450mm | Chassis Width | 1000MM |
| Carriage Dimensions | 1600*1200*500mm | Ground Contact Length | 1400 |
| Battery Specification | Single 120A (Nationwide Warranty) | Gearbox Model | Guli Type 18 |
| Engine | Quanchai 18HP, Single-cylinder Water-cooled | Crawler Specification Model | 230*72*58 |
| Self-weight | 864kg | Load-bearing Configuration (Cast Iron) | 6 pieces of 150 load-bearing wheels |
| Product Model | 4-ton car type | Power | 40kw/55Ps |
| Overall Dimensions | 3500*1690*1700MM | Chassis Width | 1520MM |
| Carriage Dimensions | 2200*1600*560MM | Ground Contact Length | 1730 |
| Battery Specification | Two 80A (Nationwide Warranty) | Gearbox Model | Guli 23-1200 Type |
| Engine | Huichai or Weifang Series, Four-cylinder 490 | Crawler Specification Model | 320*90*56 |
| Self-weight | 1500kg | Load-bearing Configuration (Cast Iron) | Standard: 8 integrated load-bearing wheels (180 each) per side |
| Product Model | 6-ton car type | Power | 58kw/79Ps |
| Overall Dimensions | 3750*1800*1750MM | Chassis Width | 1600MM |
| Cargo Box Dimensions | 2600*1800*660MM | Ground Contact Length | 2200 |
| Battery Specification | Two 80A (Nationwide Warranty) | Gearbox Model | Guli Type 29-1200 |
| Engine | Yuchai Power 490 Turbocharged | Crawler Specification Model | 400*90*68 |
| Self-weight | 2000kg | Load-bearing Configuration (Cast Iron) | Standard: 9 integrated load-bearing wheels (180 each) per side |
| Model | 8T Transporter | Starting Method | Electric Start |
| Rated Load | 8T | Chassis Width / mm | 2050 |
| Self-weight | 4.5 tons | Tensioning Device | Hydraulic Tensioning |
| Gearbox Model | 545 Gearbox | Battery | 24V |
| Rear Axle | 1098 | Driving Method | Drive Shaft Drive |
| Overall Dimensions (L*W*H) | 4420*2050*2350 | Braking Method | Pneumatic Brake |
| Cargo Box Dimensions (L*W*H) | 2600*2000*700 (Bottom 3, Sides 2) | Climbing Angle | 35 Degrees |
| Crawler (Model) | 400-90-70 Engineering Crawler | Self-unloading Function | Hydraulic Dual-top Self-unloading |
| Ground Contact Length | 2000 | Engine | Weifang (Yangma) |
| Number of Carrier Rollers | Single side: Two fixed solid wheels, three groups of 200 cast steel floating wheels in the middle | Engine Model | 4108 Intercooled Turbocharged |
| Gears | 10+2 | Engine Power | 88kw/120ps |
The tracked transport vehicle relies on strong grip tracks and narrow body design, with a wide range of applications: It can smoothly pass through narrow mountain roads and efficiently complete wood transportation; can stably carry concrete loading operations and adapt to the needs of construction sites; deeply transport agricultural materials and fruits in agricultural and forestry orchards, without fear of soft soil in the fields; during snow transportation, the anti slip performance is outstanding, making it easy to cope with icy and snowy road conditions, and comprehensively solving the problem of material transportation in complex environments.
Shandong tuoyuan machinery manufacturing co., ltd. Is located in jining, shandong, the core cluster area of the construction machinery industry. Since entering the industry in 2014, it has accumulated 11 years of professional experience in the production and manufacturing of construction machinery, especially in the field of characteristic products such as tracked transport vehicles, forming a mature technical system. The company has gradually developed into a comprehensive enterprise integrating new product research and development, intelligent manufacturing, and e-commerce operations. It always adheres to the development concept of “Quality as the foundation, innovation as the driving force”, relying on a professional and efficient management team, a strict quality inspection system throughout the process, customized production services that can adapt to work conditions, and efficient logistics support covering the world. It has established long-term and stable partnerships in europe, america, southeast asia, australia, peru and other places, and has steadily grown from a local manufacturer to a modern manufacturing enterprise with strong independent research and development capabilities and a global perspective.
Q1: How long is the warranty for this machine?
A: One year.
Q2: Are you the original manufacturer?
A: Yes. We are a construction machinery manufacturer.
Q3: Can we use our company logo on the machine?
A: Yes, sir, of course.
Q4: Do you have any international certifications?
A: Our main products are CE certified, and our production system is ISO9001 certified.
Q5: Are your quotes transparent?
A: We offer transparent quotes, clearly listing product unit prices, packaging fees, shipping costs, and other items. Before you place an order, we will provide a detailed “Fee Detail Sheet” for your review.
Q6: What is the minimum order quantity (MOQ)? Can you support small trial orders?
A: 1 unit, yes.
Q7: What is the production lead time?
A: The production lead time for standard products is generally 8-15 business days after receiving the deposit. After the order is confirmed, a production schedule will be issued and you will be updated on the production progress.
Q8: What are the payment methods?
A: Our standard payment method is a 30% deposit and a 70% balance.
Q9: What if the product has quality issues or is damaged upon arrival?
A: We offer a one-year warranty on core components. If any issues arise, our engineers will first provide remote online diagnosis and guidance, and then provide warranty service.
Q10: What if the product is damaged during sea transportation?
A: Upon request, we will purchase shipping insurance for the machine.
